ARJ Series SCARA Robot (2-5kg)
The
AJR Series 2-5kg is specially designed for industries requiring high cleanliness combined with precision manipulation in confined spaces.
- Semiconductor manufacturing: Used for silicon wafer transfer and other processes requiring ISO Class 4 cleanliness compliance. The robot's particle-free operation ensures product quality and production safety.
- Pharmaceutical and medical industry: Ideal for drug encapsulation and handling of medical materials where contamination control is of paramount importance.
- Precision electronics manufacturing: Provides the cleanliness and accuracy required for sensitive components, including glass panel handling.
- Food industry and packaging: The cleanliness class and IP65 protection make the robot suitable for hygienic environments. Typical tasks include loading and unloading, material handling, packaging, assembly, and inspection.
The robot's compact ceiling-mounted design is particularly valuable in applications with limited floor space, such as automated existing production lines or cleanrooms where floor area must be minimized.
Arm length: 550 mm
Rated / maximum load: 2 kg / 5 kg
Repeatability: ±0.01 mm
Cleanliness class: ISO Class 4 (equivalent to Class 10)
Protection rating: IP65
Standard cycle time: 0.39 s
Number of axes: 4
Mounting type: Ceiling-mounted / inverted
Robot weight: 24 kg
Key advantages: Compact ceiling-mounted design for space saving, combination of ISO Class 4 cleanliness and IP65 protection rating for operation in hygienic and clean environments.
We provide tailored solutions, which means every quote is unique.
To give you an accurate estimate of delivery cost and lead time, we'll review your specific project needs, order quantity, and technical requirements upon request.
